Engineering/Computer Aided Design/Manufacturing
- EzCam used for CNC operations
- Variety of software for design applications
Machining Equipment:
- Two Computer Numerically Controlled (CNC) milling machines
- Two Electrostatic Discharge (spark erosion) Machines (EDM),
one traveling wire EDM with 10x15x15 inch capacity, and one
ram-type (sinker) EDM with 8x8x12 inch capacity.
- Seven vertical milling machines with capabilities form 250 to 700
pounds and travels from 28 to 41 inches, most with digital
positioning (0.0005 inch resolution)
- Two jig boring machines with capabilities to 600 pounds and
positional accuracies to 0.0001 inch.
- Horizontal boring mill with a capacity of 1500 pounds,
36 x 36 x 48 inches travels, and 0.0005 inch resolution
- Seven tool room or engine lathes with capacities from 10 x 18
inches up to 50 x 120 inches, including one lathe equipped for
contouring by servo-tracer
- Sheet metal fabrication equipment including power and manual
shears and brakes, rolls and punches
- Horizontal power band saw, 12 x 12 inch capacity
- Two vertical band saws 18 and 28 inch capacity (one equipped
with hyd. feed) and Plate shear rated 3/8 mild steel x 72 inch
- Diamond abrasive cut-off saw
- Universal tool room grinder
- Surface grinder, 18 x 6 inch travels
- Power tapping station #4 to 9/16 capacity
- Five drill presses, from .5 to 5 hp., including a 30 inch
radial-arm drill with tapping rated 3 inch diameter mild steel
- Miscellaneous woodworking, sanding and grinding equipment
Welding Equipment:
- Separate shop equipped for TIG (GTAW), MIG (GMAW),
stick (SMAW) and Oxy-Acetylene welding, gas and plasma
cutting, soldering and brazing
- Leyboldt-Heraeus High Vacuum Leak Detector
Heat Treating:
- Two heat treating furnaces, one capable of wet or dry Hyrogen
or inert gas annealing, plus a large stress relieving oven for
aluminum or plastic parts
Inspection Equipment:
- Digital Height Gage - 18 inch capacity with
.0001/.001 mm resolution
- 4 x 5 foot laboratory grade Surface Plate
- Micro-inch Comparators
- Dimensional Standards traceable to NIST
- 18 inch Optical Comparator (shadowgraph) - 10 to 100x
- Electronic Surface Roughness Gauge - 1 to 100 micro inch
- .0002 resolution bore gauge to 4.5 inch diameter
- Toolmaker's microscope
- Wilson Hardness Tester (Rockwell B,C)
The MDG will occasionally surplus equipment to make room for new equipment or to reorganize. When this occurs we are required to follow the University's guidelines, thus any such equipment will be disposed of through Terrapin Trader. It is expected that most of these will be "Bid items," so please feel free to peruse their website.
|
